Lifepo4 Powerwall Solar Battery Energy Storage Pack 5kwh 48v 51.2v 50ah 100ah

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : negotiated

Battery Type : LiFePO4

Output Power Range : 5~10 kWh

Dimension (L*W*H) : 56*55*18cm

Weight : 50kg

Protection Class : IP20

Nominal Capacity : 100AH

Contact Now

PowerWall 5kwh 51.2v 100ah Lithium Ions Battery 48v 50ah 100ah Lifepo4 Pack Power Wall Solar Energy Storage Battery

Specification	Battery Module	Battery Module	Powerwall
Model	51.2V 100AH	LFP 48V 50Ah	LFP 48V 100Ah
Nominal Capacity [Ah]	100AH	50Ah	100Ah
Nominal Energy [kWh]	5.12kwh	2.4kWh	5.12kWh
Nominal Voltage [V]	51.2V (Working Voltage 45~57V)	48VDC (Working Voltage 45~57V)
Max. Charge/Discharge Current	75A	50A	75A
Net Weight	50KG(110IBS)	22kg (48.5 lbs)	50kg (110 lbs)
Life Cycles	6000+	3500+	6000+
Dimension (WDH)	558545150mm	48036090 mm (18.914.23.5 inch)	558545150 mm (21.921.45.9 inch)
Communication	CAN/RS485/RS232	CAN/RS485	CAN/RS485/RS232/DRY CONTACT
Certification & Safety Standard	TUV/CE/IEC6219/UN38.3/MSDS	TUV/CE/UN38.3/MSDS	CE/MSDS/UN38.3/TUV/EMC
Warranty	5-10 Years
Charging Temp. Range	0~55℃
Discharging Temp.Range	-20~55℃
Alarms	Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit
Pros	Can be used in both off-grid and hybrid setups, compact design
Compatible Inverters	Victron/SMA/Goodwe/Imeon/Solis/SAJ/Growatt/Luxpower/Voltronic/Deye etc
OEM/ODM	Yes (Accepted)
Protection	Smart BMS protection in each Module to protect battery safety

Product details

Lifepo4 Powerwall Solar Battery Energy Storage Pack 5kwh 48v 51.2v 50ah 100ah

Please contact us for more details of inverter.

Range of application

Home Energy Storage Systems · Solar Energy Storage Systems · Electric Power Systems

Attractive Design

ERHTWONE BX51100 adopts economic design, tailor-made for residential and light commercial. Our lithium iron phosphate battery energy storage system can provide energy storage for photovoltaic power generation users through parallel combination.

Powerful Performance

Our product can store extra electricity into battery from photovoltaic power generation system in daytime and supply stable power
to user’s equipment as power backup at nighttime or any time when needed. It can improve the efficiency of photovoltaic power
generation and increase the electric power efficiency by peak load shifting.

Interface Definition

This section elaborates the interface functions of the front interface of the device. It's integrated BMS communication protocol to comprehensive hybrid and off grid inverters.

Why Choose Us

◆ Technology

We use advanced technology and production processes at home and abroad

◆ Capacity

Our company cover wide area and has strong production capacity and convenient transportation

◆ Quality

Our products have affordable price, and most importantly, we have strict quality control system

◆ Service

Our company has professional production technicians and presales customer service staff

FAQ

Q: How long is the warranty period?
A: Our limited warranty is valid for a period of 5 years after delivery. It is restricted by specifications and warranty terms.

Q: Can we print our logo on products?
A: Of course, we can provide one to one customized OEM with a MOQ demand.

Q: How long is the estimated delivery time?
A: The delivery time is usually 28 days after receiving the payment.

Q: Are you able to handle shipment transportation?
A: Sure, we can arrange the shipment to most places as required.

Q: What kind of certification do you have?
A: In general, we have SGS TÜV Saar, IEC 62040-1, IEC 62109-1, IEC 62109-2, IEC 62619, UN38.3, IEC 62133, CEC, UL, MSDS, ISO 9001 certifications, but each type of product may be different.

Q: What kind of product quality your factory offer?
A: We provide the most competitive products at the highest quality price.
